Ortur H10 Specifications

The Ortur H10 is a beginner-friendly, pre-assembled laser engraver designed for creators who want to get started quickly without complicated setup. Powered by a high-performance 10W or 20W laser module and capable of speeds up to 20,000 mm/min, the H10 offers the perfect blend of power, speed, and ease of use.

Shop Now

Main Features

  • Power System: 24V 6A
  • Engrave Area: 300mmx300mm
  • Construction Material: 99% Aluminium Alloy + 1% Rubber
  • Maximum Engraving Speed: 20,000mm/min
  • Features:
      - 2.4G Wifi, USB, SD Card, FTP and WebUi Control
      - Exposure Duration and Limitation
      - Active G-shock and Gyroscopic Sensor

Compatible Laser Modules

  • LU3-20B 20W Module
    Optical Power Output: >20,000mW
    WaveLenght: 445nm
    Focal Lenght: 46mm
    Dot Size: 0.1×0.12mm
    Modulation Mode: PWM
    Weight: 555g

Specifications

Ortur H10 Specifications
Product Ortur Laser Master H10
Motherboard OLM-ESP-H10_V2.7
Firmware ESP_H10_218
Safety Features 1. Active Position Protection
2. Exposure Duration Detection and Limitation
3. Laser Beam Safety Guard
4. Sloping Position Protection
5. Host Computer Watchdog
6. Wifi, FTP and SD Card Reader
Frame Materials 70% Aluminium, 15% Stainless Steel, 5% Plastic, 5% Brass, 5% Others
Motors NEMA17 Stepper Motors
Mechanical Precision Y: 12.5um，X: 12.5um
Pixel Accuracy Adjustable – (Default: 300 DP; roughly 0.81um Pixel Accuracy)
Engraving Area 300mm*300mm
Available Laser Modules LU3-20B – Optical Power: >20,000mW
LU3-20A – Optical Power: 20,000~24,000mW
LU2-10A – Optical Power: >9500mW
LU2-4 SF– Optical Power: 5,000~5,500mmW
LU2-4 LF – Optical Power: 5,000~5,500mmW
Wave Length 445±5nm
Focus Fixed Focus
Default Focal Length 46mm (from the heat sink to the object)
Control Mode PWM
Power Rate S0-S1,000
Engraving Speed 0-20,000mm/min
Baud Rate 115200 – 921600 (Default: 115200)
Computer OS Win XP, Win 7, Win 8, Win 10 (LaserGRBL)
Mac and Linux (LightBurn)
Control Softwares LaserGRBL (free), LightBurn (Paid Software)
Input Format JPG, JPEG, PNG, BMP, SVG, etc.
Available Materials of Engraving Wood Board, Paperboard, Black Acrylic, Leather, Food, Stainless Steel, Power Coated Metal, etc.
Available Materials of Cutting Wood Board, Paperboard, Black Acrylic, Leather, Felt Cloth, Dark Color Plastic Sheet (Melt), etc.
Input Voltage 100-240~50/60Hz
Power Adapter Output 24V/6A
Operating Temp -5℃ – 50℃
